Wintex 3000

Wintex 3000

The Wintex 3000 – automatic soil samples up to 90 cm in all soils. Soil samples from three layers in just one sampling process. Accurate splitting of samples, three soil boxes. Depth individually adjustable. Highly efficient, reliable and robust.

Key features:

  • Sample/hour:                 15
  • Sticks/hour:                   1 stick in 22-28 sec.
  • Sticks/sample:               14-16
  • Volume/sample:             available with 26 mm probe for1,5 g/cm, 2,0 g/cm or 2,5 g/cm
  • Diameter probe:             26 mm
  • Hydraulic system:           Honda GX200, 5,5 hp
  • Hydraulic consumption:  16 l/min, 100 bar
  • Hydraulic tank:               7 liters
  • Electrical power:             12 V DC
  • Net weight:                     95 kg

Contact us
Benefits of thesolution

The WINTEX 3000 can take soil samples from up to three layers in just one operational step. The samples can be taken from one, two or three layers at the same time. The total depth as well as the point at which the sample shall be divided can be adjusted infinitely variable according to the user’s needs. The soil samples are always taken at the exact same depth. They are divided precisely at the defined points and filled into the soil boxes.

The WINTEX 3000 works in any type of soil also in clayey, sandy or really hard soil. The soil samples are taken by a soil sampler probe and not with an auger. This ensures a completely homogeneous sample. If a sample is taken with an auger, you will always take more material from the top layers than from the lower layers of the soil which influences the accuracy of the sample.

Get manual
